Nm360 Nm400 Ar500 Wear Resistant Steel Plate

  • Nm360 Nm400 Ar500 Wear Resistant Steel Plate
  • Nm360 Nm400 Ar500 Wear Resistant Steel Plate
  • Nm360 Nm400 Ar500 Wear Resistant Steel Plate
  • Nm360 Nm400 Ar500 Wear Resistant Steel Plate

Nm360 Nm400 Ar500 Wear Resistant Steel Plate

    Packaging: Standard marine packaging or according to customer requirements
    Productivity: 10000Tons per month
    Brand: H-TONG
    Transportation: Ocean,Land,Express,Air
    Place of Origin: Shandong
    Supply Ability: 10000Tons per month
    HS Code: 7208520000
    Port: Tianjin Port,Qingdao Port,Shanghai Port

Basic Info

Model No.: NM 400/500

Product Description


Wear Resistant Steel Plate

It refers to special plate products specially used under large-area wear conditions. The commonly used wear-resistant steel plate is made of ordinary low-carbon steel or low-alloy steel with good toughness and plasticity by surfacing with a certain thickness of alloy wear-resistant layer with high hardness and excellent wear resistance. In addition, there are cast wear-resistant steel plates and alloy quenched wear-resistant steel plates.


Wear resistant steel plate is composed of low-carbon steel plate and alloy wear-resistant layer. The alloy wear-resistant layer is generally 1 / 3 ~ 1 / 2 of the total thickness. During operation, the matrix provides comprehensive properties such as strength, toughness and plasticity to resist external forces, and the alloy wear-resistant layer provides wear-resistant properties that meet the requirements of specified working conditions.
The wear-resistant steel plate is metallurgically bonded between the alloy wear-resistant layer and the substrate. Through special equipment and automatic welding process, the high hardness self protective alloy welding wire is evenly welded on the substrate. The number of composite layers is one to two or even multiple layers. During the composite process, uniform transverse cracks appear due to different alloy shrinkage ratio, which is the remarkable feature of wear-resistant steel plate.
The alloy wear-resistant layer is mainly composed of chromium alloy, and other alloy components such as manganese, molybdenum, niobium and nickel are also added. The carbides in the metallographic structure are distributed in fiber shape, and the fiber direction is perpendicular to the surface. The micro hardness of carbide can reach above hv1700-2000 and the surface hardness can reach HRC58-62. Alloy carbides have strong stability at high temperature, maintain high hardness, and have good oxidation resistance. They can be used normally within 500 ℃.
The wear-resistant layer takes the form of narrow channel (2.5-3.5mm), wide channel (8-12mm), curve (s, w), etc; It is mainly composed of chromium alloy and other alloy components such as manganese, molybdenum, niobium, nickel and boron. The carbides in the metallographic structure are distributed in fiber shape, and the fiber direction is perpendicular to the surface. The carbide content is 40-60%, the microhardness can reach more than hv1700, and the surface hardness can reach HRC58-62.
Wear resistant steel plates are mainly divided into general type, impact resistant type and high temperature resistant type; The total thickness of wear-resistant steel plate can reach 5.5 (2.5 + 3) mm at least and 30 (15 + 15) mm at most; The wear-resistant steel plate can roll the wear-resistant pipe with the minimum diameter of DN200, and can be processed into wear-resistant elbow, wear-resistant tee and wear-resistant reducer.

Wear resistant steel are produced from processes of hot rolling, cutting into length and heat treating. The products are characterized with small thickness, good flatness, outstanding wear resistance, excellent toughness, good weldability, good machinablility, consistent property and quality.

Wear resistant steels are developed for applications where high wear resistant performance is required, such as dumper, garbage vehicle, Concrete Mixer Truck, industrial air fan, hopper, crusher, machinery for coal, grain, cement, grab bucket, etc.


Grade

NM360, NM400, NM450, NM500, NM550, NM600

Thickness

3-80mm or customized

Width

1250mm, 1500mm, 1800mm, 2000mm, 2200mm or as required

Length

6000mm, 8000mm, 10000mm, or cut to required.

Standard

AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc.

Material

NM300/360/400/450/500/600/A/B/C,etc

SM490(A, B, C), SM490Y(A, B) ,SM520(B, C), SM570,St44-3, St52-3,

St50-2, St60-2, St702, StE315, StE355, StE380, StE 420, StE 460,

StE 500,A572M (Gr. 42, 50, 60, 65),

A633M(A, B, C, D, E), A709 Grade 50,S275(

JR, J0, J2G3, J2G4)S355(JR, J0, J2G3, J2G4, K2G3, K2G4), E395

, E335, E360,S275N, S275NL,

S355N, S355NL, S420N, S420NL, S460N, S460NL,S460Q S460QL

S460QL1 S500Q S500QL

S500QL1 S550Q S550QL S550QL1 S620Q,S620QL S620QL1 S690Q

S690QL S690QL1

S890Q S890QL S890QL1 S960Q S960QL,S275M, S355M, S420M,

S460M, S275ML, S355ML,

S420ML, S460ML,A588 (Gr. A, B, C, K),

A514 (Gr. A, B, L, E, F, H, J, K, M, P, Q, R, S, T)
S235J0W S235J2W S355J0WP S355J2WP

S355J0W S355J2W S355K2
A573 Grade 58, A573 Grade 65, A573 Grade 70 A 573/A 573M,

A588 Grade A, A588 Grade B,

A588 Grade C, A588 Grade K A 588/A 588M,A633 Grade A, C, D,

E Normalized high strength

low alloy structural steel plate,A572 Grade 42, A572 50, A57255,

A572 Gr. 60, A572 Gr. 65
Improved Formability A656 Grade 50, 60, 70, 80
Structural Steel for bridges A709 Grade 36, 50, 50S, 50W,

HPS 50W, HPS 70W,

100, 100W, HPS 100

Technique

Hot rolled, cold rolled

Surface Treatment

Coated or galvanized

Application

Shipbuilding, car, bridge, pressure vessels and so on

Packaging

Export standard package or as required.

Terms of payment

L/C,T/T, Western union,or as required.







Standard shipping packaging or according to customer requirements


Support sea transportation, air transportation, land transportation and express delivery

Q: Who and where are you?
Shandong Huitong Steel Co., Ltd. is a large steel production enterprise. Our main production base is located at Liaocheng city, shandong province, China.
Q:What kind of metal material does your company do?
Our production scope involves seamless steel pipes, galvanized steel products, stainless steel products, steel plate, customized heterosexual steel pipes and other steels.
Q:What are the advantages in price and quality ?
To offer good quality and competitive price is our company principle.
We can offer our customer good and reasonable price.
Q: OEM Service is acceptable?
Yes, OEM severvice is available.
Q: Payment term and Lead time
A: Payment term is depending on target market condition,order amount,shipment schedule.., or 30% T/T in advance ,balance will be paid against BL copy or LC at sight.
B: Delivery time: for most of pipe,plate, coil.. the lead time is at around7- 15days. For larger order plate, it is subject to the steel plant production order, but. Base on our larger purchasing oder from steel mill, we can assure our customer the delivery date is soon.

SHANDONG HUITONG STEEL CO.,LTD

 Shandong Huitong Steel Co.,ltd is located in Liaocheng City, Shandong Province, China. Our sales range covers seamless steel pipe, galvanized steel products, carbon steel plate, customized special-shaped steel pipe and other steel products. We have established a sound scientific management and quality assurance system. We can customize metal products according to customers' drawings and samples. With excellent and stable quality, reasonable price and thoughtful and efficient service, we are committed to continuously improving product quality and service level and serving more customers, making Guanzhou your preferred steel procurement supplier. Guanzhou has a professional and efficient international trade team, which can better serve customers. Guanzhou supply Supply the world!
